Chameleon Color Shifting Metallic Powder Coating epoxy polyester Paint

Brand Name : Hsinda

Model Number : Chameleon

Certification : ISO9001; SGS; ROHS,AAMA,FDA

Place of Origin : Chengdu

MOQ : 100kg

Price : 10USD/KG

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 50000TONS/YEAR

Delivery Time : 3-7 days after payment

Packaging Details : Inner packing :polyethylene bag; Outer packing :paper carton

Main Raw Material : epoxy, polyester ,epoxy polyester etc

State : Powder state

Gloss : FLAT

Main Type : epoxy ,polyester ,epoxy polyester powder coating

Raw Materials Brand : DSM resin , Dupont etc

Curing : 180-200℃,15 min

Particle Size : Average 30-42μm

surface : smooth

Contact Now

Chameleon Color Shifting Metallic Powder Coating epoxy polyester Paint

Product Description
Powder coating is a solvent-free solid coating that is directly sprayed onto the surface of an object in dry powder form and solidified by heating to form a coating
Chameleon Color Shifting Metallic Powder Coating epoxy polyester Paint

Main components
Resin: such as epoxy, polyester, polyurethane, etc., determines the coating performance (weather resistance, hardness, etc.).

Curing agent: Reacts with resin to form a stable coating.

Pigments: provide color and coverage.

Additives: such as leveling agents, texturing agents, to improve appearance or functionality.

Key Features
Environmental Protection: Non volatile solvents (VOCs) reduce pollution and fire risks.

Efficient: Spraying can recycle excess powder, with a utilization rate of over 95%.

Durable: The coating is impact resistant, corrosion-resistant, and resistant to chemicals, suitable for harsh environments.

Diversification: Different gloss and texture (such as sanding and metallic effects) can be adjusted.

Chameleon Color Shifting Metallic Powder Coating epoxy polyester Paint

Processing


Electrostatic spraying: Powder is charged and adsorbed onto the workpiece, and then baked and solidified (usually 180-200 ℃).

Fluidized bed: Preheating the workpiece into powder, suitable for thick coatings (such as pipelines).

.

Common uses


Household appliances: refrigerator, washing machine casing.

Building materials: doors and windows, aluminum profiles.

Automobiles: wheel hubs, chassis components.

Industrial equipment: fields with high anti-corrosion requirements such as agricultural machinery and shelves.

Product overview

Chameleon Color Shifting Metallic Powder Coating epoxy polyester Paint

Type

Epoxy Powder Coating; Polyester Powder Coating;

Epoxy-Polyester Powder Coating

Color Ral&Pantone color
Surface Finish Superior gloss and color retention
Particle Size Average 32-42μm
Specific Gravity 1.2-1.7g per cubic meter
Coverage 8-10 square meters per Kg at 30-90 μm film thickness
Film thickness Not less than 100μm

Instruction

Application Voltage 60-90 KV
Gun to Component Distance 15-30CM
Curing Temperature 180-200℃,10 min-15 min

Storage stability

Store in ventilated, dry, clean room, temperature < 25 Relative humidity 50-65%
Away from direct sunlight, fire, heat For best performance, use within 6 months

Product process

Chameleon Color Shifting Metallic Powder Coating epoxy polyester Paint

Trade items of Products

Trade terms FOB, CIF,CRF,CNF
Payment terms T/T, L/C , West Union ,Moneygram , Paypal etc
Payment condition 30% deposit in advance,70% balance before shipment
Delivery time 3-7 days after deposit
Shipping By sea, by air and by express delivery
Sample Powder will be delivery by courier ,like DHL,UPS,FEDEX etc. 5-8 DAYS to arrival
Official Order Powder will be ship by SEA .15-30 DAYS to arrival

Chameleon Color Shifting Metallic Powder Coating epoxy polyester Paint

Quality control:

Test Item Test Method Test Result
Film Thickness ISO2360 60-80um
Pencil Hardness ASTMD 3363 HB-H
Bending ISO1519 ≤10mm
Grid Test 1mm ISO2409 0 Class
Impulse Test ASTMD2794 Pass
Cupping Test ISO1520 ≥8mm
Heat Resistance 1000 hours ISO6270-1 Popping<1mm
Shigh gloss mirror chrome sliver spray paint powder coating Spray 1000 hours ISO9227

Corrosion Spreading<1mm
